MARINE & WORK BOAT AIR CONDITIONERS

GENERAL DESCRIPTION

The Marvair Marine remote condenser air conditioners and air handlers are designed for both new installations and for replacement of older, less efficient units in marine applications. The air conditioners are available in cooling capacities of 5, 7½, 10, 12, 15 and 20 tons (60,000, 90,000, 120,000, 144,000, 180,000 & 240,000 BTUH’s) and are controlled by a conventional 24 VDC wall mounted, HVAC type thermostat. The vertical configuration minimizes floor space and blends into a variety of working environments. The cool, dry air can be discharged directly into the room or ducted into adjacent rooms. All service and maintenance is performed from the front or side of the unit- no need to move the unit for service or maintenance. To ensure years of dependable performance, all components are housed in a superior corrosion resistant steel cabinet. The galvaneal steel is bonderized and followed by a heat cured enamel neutral gray finish.

AIR COOLED UNITS

The MVS air cooled units have an indoor air mover, coil, compressor and controls. A remote condenser (not provided by Marvair) connects to the MVS unit with field installed refrigerant lines. The units are shipped with a dry nitrogen charge and may be used with either R-22 or R-407c refrigerant.

WATER COOLED UNITS

The MVW water cooled air conditioners are packaged units shipped from the factory with R-407c refrigerant and are ready to connect to a remote keel cooler. The coaxial tube-in-tube condenser is constructed of corrosion resistant cupronickel water tubing and copper refrigerant tubing for use in either fresh or sea water.

For detailed specifications, performance, and efficiency information, download the Product Data Sheet from the document list on this page.
